Japan – Milestone of THz Communication

June 30, 2022

Scientists from a project coordinated by Technische Universitat Braunschweig in Germany and Waseda University in Japan with ten other partners from five countries have succeeded for the first time worldwide in developing a bidirectional THz radio link that can be connected as a “backhaul” to the data network of mobile radio providers. This link achieved by the Horizon Europe-funded new windowThoR project, can realise high data rates and thus play an important role in the network infrastructure of the future. On 29 and 30 June, the THz radio link will be presented in a final workshop of the ThoR project.

The Braunschweig radio relay link connects the Oker Tower with TU Braunschweig’s IT Centre over a distance of 160 metres. Credits: Thomas Kürner/ TU Braunschweig

Fibre-optic cables are not always the best option when it comes to transmitting data. Especially in cities, it is often not possible to connect every base station of the mobile network by cable. Radio relay links provide an alternative solution. With the help of antennas mounted on roofs, they can bridge distances of up to one kilometre. This creates important backhaul connections between mobile radio cells and the nodes of the mobile radio network without the need for any road construction work.

Until now, the high data rates produced by the 5G mobile communications standard, which will continue to increase in the future 6G standard, favoured a fibre-optic connection between stations to the data networks. The international ThoR project has now succeeded in developing a bidirectional terahertz radio link that can reliably transmit these high data volumes. The frequency range above 300 gigahertz is used for this as it offers enough spectrum for high data rates.

The ThoR-backhaul link is the only one of its kind in the world to offer a bidirectional real data connection and connects TU Braunschweig’s IT centre with the Oker high-rise building over a distance of 160 metres. It can transmit data rates of 2×20 Gbit/s net at a bandwidth of 2×8.64 GHz and is scalable over the bandwidth so that higher data rates can also be realised. Professor Thomas Kurner, coordinator of the European part of the project: “We have realised an application-oriented complete solution here, which can already be used as a backhaul link in the data network in the near future.” In addition, as the first backhaul link of its kind, its functionality also complies with the IEEE 802.15.3 standard. The IEEE 802.15.3 standard was already developed in the run-up to the ThoR project and substantial research contributions were made by TU Braunschweig and several of the Japan-based partners.

On 29 and 30 June, the final workshop of the ThoR project will take place in hybrid form. In addition to attending the workshop in person in the Aula of the Haus der Wissenschaft (Pockelstrabetae 11, 38106 Braunschweig), it will also be possible to participate online. The core of the workshop is the demonstration of the backhaul track with a tour of the developed THz hardware. Registration for the workshop is possible new windowonline.

The ThoR project is funded by the EU through the Horizon 2020 research framework programme (Grant Agreement 814523) and by the National Institute of Information and Communications Technology in Japan with a total of three million euros. The project started on 1 July 2018 and will end on 30 June 2022.

Partners of the ThoR project:
TU Braunschweig (EU coordinator, Germany), Waseda University (Japanese coordinator, Japan), Chiba Institute of Technology (Japan), Gifu University (Japan), University of Stuttgart (Germany), Fraunhofer Institute for Applied Solid State Physics IAF (Germany), University of Lille-CNRS IEMN&PhLAM Laboratories (France), HRCP R&D Partnership (Japan), Vivid Components Ltd (UK), Siklu Communication Ltd (Israel), NEC Corporation (Japan) and Deutsche Telekom (Germany/Czech Republic).

Further information can be found at: https://thorproject.eu/
